Introduction
Table 1
Considered problems | Authors |
Pattern recognition problems | Meng and Chen (2016) |
Bridge risk assessment | Shen et al. (2016) |
Ranking investment alternatives | Zavadskas et al. (2015), Hashemi et al. (2015), |
Zavadskas et al. (2014), Razavi Hajiagha et al. (2013b) | |
Air-condition system selection | Hashemkhani Zolfani et al. (2015), Liu and Wang (2007), |
Lin et al. (2007) | |
Tourism management | Chu and Guo (2015) |
Revitalization of buildings | Zavadskas et al. (2014) |
Customer satisfaction determination | Razavi Hajiagha et al. (2013a) |
Personnel selection | Wan et al. (2013) |
Medical diagnosis | Chen (2015), De et al. (2001) |
1 Preliminaries
1.1 Some Basic Concepts Related to Intuitionistic Fuzzy Sets
(1)
\[ \tilde{A}=\big\{\big\langle x,{\mu _{A}}(x)\big\rangle \hspace{0.1667em}\big|\hspace{0.1667em}x\in X\big\},\](2)
\[ \tilde{A}=\big\{\big\langle x,{\mu _{A}}(x),{\nu _{A}}(x)\big\rangle \hspace{0.1667em}\big|\hspace{0.1667em}x\in X\},\]1.2 Triangular Intuitionistic Fuzzy Numbers
(11)
\[ \mu (x)=\left\{\begin{array}{l@{\hskip4.0pt}l}0,\hspace{1em}& x<l,\\ {} (x-l)/(m-l),\hspace{1em}& l\leqslant x\leqslant m,\\ {} (u-x)/(u-m),\hspace{1em}& l\leqslant x\leqslant u,\\ {} 0,\hspace{1em}& x>u.\end{array}\right.\](12)
\[ \mu (x)=\left\{\begin{array}{l@{\hskip4.0pt}l}\omega (x-l)/(m-l),\hspace{1em}& l\leqslant x<m,\\ {} \omega ,\hspace{1em}& x=m,\\ {} \omega (u-x)/(u-m),\hspace{1em}& m<x\leqslant u,\\ {} 0,\hspace{1em}& \text{otherwise},\end{array}\right.\](13)
\[ \nu (x)=\left\{\begin{array}{l@{\hskip4.0pt}l}[{m^{\prime }}-x+{\omega ^{\prime }}(x-{l^{\prime }})]/({m^{\prime }}-{l^{\prime }}),\hspace{1em}& {l^{\prime }}\leqslant x\leqslant {m^{\prime }},\\ {} {\omega ^{\prime }},\hspace{1em}& x={m^{\prime }},\\ {} [x-{m^{\prime }}+{\omega ^{\prime }}({u^{\prime }}-x)]/({u^{\prime }}-{m^{\prime }}),\hspace{1em}& {m^{\prime }}<x\leqslant {u^{\prime }},\\ {} 1,\hspace{1em}& \text{otherwise},\end{array}\right.\](14)
\[ \tilde{A}+\tilde{B}=\big\langle ({a_{l}}+{b_{l}}-{a_{l}}{b_{l}},{a_{m}}+{b_{m}}-{a_{m}}{b_{m}},{a_{u}}+{b_{u}}-{a_{u}}{b_{u}}),\big({a^{\prime }_{l}}{b^{\prime }_{l}},{a^{\prime }_{m}}{b^{\prime }_{m}},{a^{\prime }_{u}}{b^{\prime }_{u}}\big)\big\rangle ,\](15)
\[ \tilde{A}\cdot \tilde{B}=\big\langle ({a_{l}}{b_{l}},{a_{m}}{b_{m}},{a_{u}}{b_{u}}),\big({a^{\prime }_{l}}+{b^{\prime }_{l}}-{a^{\prime }_{l}}{b^{\prime }_{l}},{a^{\prime }_{m}}+{b^{\prime }_{m}}-{a^{\prime }_{m}}{b^{\prime }_{m}},{a^{\prime }_{u}}+{b^{\prime }_{u}}-{a^{\prime }_{u}}{b^{\prime }_{u}}\big)\big\rangle .\](19)
\[\begin{array}{l}\displaystyle \mathit{TIFWA}({\tilde{A}_{1}},{\tilde{A}_{2}},\dots ,{\tilde{A}_{n}})\\ {} \displaystyle \hspace{1em}=\Bigg\langle \Bigg(1-{\prod \limits_{j=1}^{n}}{\big(1-{l^{\prime }_{j}}\big)^{{w_{j}}}},1-{\prod \limits_{j=1}^{n}}{\big(1-{m^{\prime }_{j}}\big)^{{w_{j}}}},1-{\prod \limits_{j=1}^{n}}{\big(1-{u^{\prime }_{j}}\big)^{{w_{j}}}}\Bigg),\\ {} \displaystyle \hspace{2em}\Bigg({\prod \limits_{j=1}^{n}}{l_{j}^{{w_{j}}}},{\prod \limits_{j=1}^{n}}{m_{j}^{{w_{j}}}},{\prod \limits_{j=1}^{n}}{u_{j}^{{w_{j}}}}\Bigg)\Bigg\rangle ,\end{array}\]2 Procedures for Ranking TIFNs
2.1 The Procedure for Ranking TIFNs Based on Score Function
2.2 The Procedure for Ranking TIFNs Based on the Use of Distances from the Ideal and Anti-Ideal Point
(20)
\[\begin{aligned}{}{\tilde{A}_{j}^{\ast }}=& \big\langle \big({l_{j}^{\ast }},{m_{j}^{\ast }},{u_{j}^{\ast }}\big),\big({l_{\prime \hspace{0.1667em}j}^{\ast }},{m^{\prime \hspace{0.1667em}\ast }_{j}},{u^{\prime \hspace{0.1667em}\ast }_{j}}\big)\big\rangle \\ {} =& \Big\langle \Big(\underset{i}{\max }{l_{ij}},\underset{i}{\max }{m_{ij}},\underset{i}{\max }{u_{ij}}\Big),\Big(\underset{i}{\min }{l^{\prime }_{ij}},\underset{i}{\min }{m^{\prime }_{ij}},\underset{i}{\min }{u^{\prime }_{ij}}\Big)\Big\rangle ,\end{aligned}\](21)
\[\begin{aligned}{}{\tilde{A}_{j}^{-}}=& \langle \big({l_{j}^{-}},{m_{j}^{-}},{u_{j}^{-}}\big),\big({l_{\prime \hspace{0.1667em}j}^{-}},{m^{\prime \hspace{0.1667em}-}_{j}},{u^{\prime \hspace{0.1667em}-}_{j}}\big)\rangle \\ {} =& \Big\langle \Big(\underset{i}{\min }{l_{ij}},\underset{i}{\min }{m_{ij}},\underset{i}{\min }{u_{ij}}\Big),\Big(\underset{i}{\max }{l^{\prime }_{ij}},\underset{i}{\max }{m^{\prime }_{ij}},\underset{i}{\max }{u^{\prime }_{ij}}\Big)\Big\rangle .\end{aligned}\](22)
\[\begin{aligned}{}{d_{i}^{+}}={\sum \limits_{j=1}^{n}}{d_{H}}\big({\tilde{a}_{ij}},{\tilde{A}_{j}^{\ast }}\big){w_{j}}=& {\sum \limits_{j=1}^{n}}\big(\big|{l_{ij}}-{l_{j}^{\ast }}\big|+\big|{m_{ij}}-{m_{j}^{\ast }}\big|+\big|{u_{ij}}-{u_{j}^{\ast }}\big|+\big|{l^{\prime }_{ij}}-{l^{\prime \hspace{0.1667em}\ast }_{j}}\big|\\ {} & +\big|{m^{\prime }_{ij}}-{m^{\prime \hspace{0.1667em}\ast }_{j}}\big|+\big|{u^{\prime }_{ij}}-{u^{\prime \hspace{0.1667em}\ast }_{j}}\big|\big){w_{j}},\end{aligned}\](23)
\[\begin{aligned}{}{d_{i}^{-}}={\sum \limits_{j=1}^{n}}{d_{H}}({\tilde{a}_{ij}},{\tilde{A}_{j}^{-}}){w_{j}}=& {\sum \limits_{j=1}^{n}}\big(\big|{l_{ij}}-{l_{j}^{-}}\big|+\big|{m_{ij}}-{m_{j}^{-}}\big|+\big|{u_{ij}}-{u_{j}^{-}}\big|\\ {} & +\big|{l_{ij}}-{l^{\prime \hspace{0.1667em}-}_{j}}\big|+\big|{m_{ij}}-{m^{\prime \hspace{0.1667em}-}_{j}}\big|+\big|{u_{ij}}-{u^{\prime \hspace{0.1667em}-}_{j}}\big|\big){w_{j}}.\end{aligned}\]2.3 The Procedure for Ranking TIFNs Based on the Use of the Hamming Distance
(25)
\[\begin{aligned}{}{\tilde{A}_{{^{j}}}^{\ast }}=& \big\langle \big({l_{j}^{\ast }},{m_{j}^{\ast }},{u_{j}^{\ast }}\big),\big({l^{\prime \hspace{0.1667em}\ast }_{j}},{m^{\prime \hspace{0.1667em}\ast }_{j}},{u^{\prime \hspace{0.1667em}\ast }_{j}}\big)\big\rangle \\ {} =& \Big\langle \Big(\underset{i}{\max }{l_{ij}},\underset{i}{\max }{m_{ij}},\underset{i}{\max }{u_{ij}}\Big),\Big(\underset{i}{\min }{l^{\prime }_{ij}},\underset{i}{\min }{m^{\prime }_{ij}},\underset{i}{\min }{u^{\prime }_{ij}}\Big)\Big\rangle .\end{aligned}\]3 Intuitionistic Fuzzy Linguistic Variables
Table 2
Linguistic variable | Corresponding triangular fuzzy number | Mode | BNPa |
Absolutely false (AF) | (0, 0, 0) | 0 | 0.000 |
Very low (VL) | (0.0, 0.0,0.1) | 0 | 0.033 |
Low (L) | (0.0, 0.15, 0.3) | 0.15 | 0.150 |
Moderate low (ML) | (0.2, 0.325, 0.45) | 0.325 | 0.325 |
Moderate (M) | (0.35, 0.5, 0.65) | 0.5 | 0.500 |
Moderate high (MH) | (0.5, 0.625, 0.75) | 0.625 | 0.625 |
High (H) | (0.7, 0.85, 1.0) | 0.85 | 0.850 |
Very high (VH) | (0.9, 1.0, 1.0) | 1 | 0.967 |
Absolutely true (AT) | (1.0, 1.0, 1.0) | 1 | 1.000 |
Table 3
Satisfaction level – affirmative attitude | Dissatisfaction level – disagreement (degree of indeterminacy)a | |||||||
Absolutely true | AF | |||||||
(AT) | (0.00) | |||||||
Very high (VH) | VL | AF | ||||||
(0.00) | (0.03) | |||||||
High (H) | L | VL | AF | |||||
(0.00) | (0.12) | (0.15) | ||||||
Moderate high | ML | L | VL | AF | ||||
(MH) | (0.05) | (0.22) | (0.34) | (0.38) | ||||
Moderate (M) | M | ML | L | VL | AF | |||
(0.00) | (0.18) | (0.35) | (0.47) | (0.50) | ||||
Moderate low | MH | M | ML | L | VL | AF | ||
(ML) | (0.05) | (0.18) | (0.35) | (0.53) | (0.64) | (0.68) | ||
Low (L) | H | MH | M | ML | L | VL | AF | |
(0.00) | (0.23) | (0.35) | (0.53) | (0.70) | (0.82) | |||
Very low (VL) | VH | H | MH | M | ML | L | VL | AF |
(0.00) | (0.12) | (0.34) | (0.47) | (0.64) | (0.82) | (0.93) | (0.97) | |
Absolutely false | AT | VH | H | MH | M | ML | L | VL |
(AF) | (0.00) | (0.03) | (0.15) | (0.38) | (0.50) | (0.68) | (0.85) | (0.97) |
4 A Framework for Evaluating Alternatives Based on the Use of TIFNs and Linguistic Variables
5 A Case Study
-
– The Stara Planina Hotel. The Stara Planina hotel (Old Mountain) is placed in the newly opened ski centre, in the mountain bearing the same name. Its website, at first available at http://hotelstaraplanina.com, is now relocated and can be found at the following address: http://www.falkensteiner.com/en/hotel/stara-planina;
-
– The Jezero Hotel. The Jezero hotel (Lake hotel), located on the coast of a beautiful reservoir, called Bor Lake. Its website is available at http://www.hoteljezero.rs/; and
-
– The Kastrum Hotel. This hotel is located in the well-known, but little utilized Serbian spa known as Gamzigradska Banja (Gamzigrad Spa). There is an archaeological site of an old Roman palace called Felix Romuliana in its vicinity. Today Felix Romuliana is under UNESCO protection because of its historical and cultural importance. The website of the Kastrum Hotel is available at: http://www.hotelkastrum.rs.
Table 4
Criteria | Weights | |
${C_{1}}$ | Reservations information | 0.22 |
${C_{2}}$ | Facilities information | 0.22 |
${C_{3}}$ | Contact information | 0.21 |
${C_{4}}$ | Surrounding area information | 0.19 |
${C_{5}}$ | Website management | 0.16 |
Table 5
Alternatives | ${E_{1}}$ | ${E_{2}}$ | ${E_{3}}$ | |||
SF levela | DSF levelb | SF level | DSF level | SF level | DSF level | |
${A_{1}}$ | VH | VL | VH | VL | VH | VL |
${A_{2}}$ | VH | VL | VH | VL | H | VL |
${A_{3}}$ | L | H | ML | M | L | MH |
Table 6
Alternatives | ${E_{1}}$ | ${E_{2}}$ | ${E_{3}}$ | |||
SF level | DSF level | SF level | DSF level | SF level | DSF level | |
${A_{1}}$ | VH | VL | H | VL | VH | VL |
${A_{2}}$ | MH | VL | VH | VL | H | VL |
${A_{3}}$ | L | M | L | MH | L | H |
Table 7
Alternatives | ${E_{1}}$ | ${E_{2}}$ | ${E_{3}}$ | |||
SF level | DSF level | SF level | DSF level | SF level | DSF level | |
${A_{1}}$ | H | L | MH | L | MH | ML |
${A_{2}}$ | H | VL | MH | ML | MH | ML |
${A_{3}}$ | H | VL | MH | VL | MH | L |
Table 8
Alternatives | ${E_{1}}$ | ${E_{2}}$ | ${E_{3}}$ | |||
SF level | DSF level | SF level | DSF level | SF level | DSF level | |
${A_{1}}$ | H | VL | MH | VL | MH | L |
${A_{2}}$ | H | VL | MH | ML | MH | ML |
${A_{3}}$ | L | VL | L | ML | VL | H |
Table 9
Alternatives | ${E_{1}}$ | ${E_{2}}$ | ${E_{3}}$ | |||
SF level | DSF level | SF level | DSF level | SF level | DSF level | |
${A_{1}}$ | M | ML | ML | M | M | ML |
${A_{2}}$ | ML | ML | M | ML | MH | ML |
${A_{3}}$ | L | VL | L | ML | VL | MH |
Table 10
Criteria Alternat | ${E_{1}}$ | ${E_{2}}$ | ${E_{3}}$ | |
${A_{1}}$ | ${C_{1}}$ | $\langle (0.9,1.0,1.0),(0.0,0.0,0.1)\rangle $ | $\langle (0.9,0.9,0.9),(0.0,0.0,0.1)\rangle $ | $\langle (0.9,0.9,0.9),(0.0,0.0,0.1)\rangle $ |
${C_{2}}$ | $\langle (0.9,1.0,1.0),(0.0,0.0,0.1)\rangle $ | $\langle (0.7,0.85,1.0),(0.0,0.0,0.1)\rangle $ | $\langle (0.9,0.9,0.9),(0.0,0.0,0.1)\rangle $ | |
${C_{3}}$ | $\langle (0.7,0.85,1.0),(0.0,0.15,0.3)\rangle $ | $\langle (0.5,0.63,0.75),(0.0,0.15,0.3)\rangle $ | $\langle (0.5,0.63,0.75),(0.2,0.33,0.45)\rangle $ | |
${C_{4}}$ | $\langle (0.7,0.85,1.0),(0.0,0.0,0.10)\rangle $ | $\langle (0.50,0.63,0.75),(0.0,0.0,0.10)\rangle $ | $\langle (0.5,0.63,0.75),(0.0,0.15,0.30)\rangle $ | |
${C_{5}}$ | $\langle (0.35,0.5,0.65),(0.2,0.33,0.45)\rangle $ | $\langle (0.2,0.33,0.45),(0.35,0.5,0.65)\rangle $ | $\langle (0.5,0.63,0.75),(0.2,0.33,0.45)\rangle $ | |
A2 | ${C_{1}}$ | $\langle (0.90,1.0,1.0),(0.0,0.0,0.10)\rangle $ | $\langle (0.9,0.9,0.9),(0.0,0.0,0.10)\rangle $ | $\langle (0.7,0.85,1.0),(0.0,0.0,0.1)\rangle $ |
${C_{2}}$ | $\langle (0.5,0.63,0.75),(0.0,0.0,0.10)\rangle $ | $\langle (0.9,0.9,0.9),(0.0,0.0,0.10)\rangle $ | $\langle (0.7,0.85,1.0),(0.0,0.0,0.1)\rangle $ | |
${C_{3}}$ | $\langle (0.7,0.85,1.0),(0.0,0.0,0.10)\rangle $ | $\langle (0.5,0.63,0.75),(0.2,0.33,0.45)\rangle $ | $\langle (0.5,0.63,0.75),(0.2,0.33,0.45)\rangle $ | |
${C_{4}}$ | $\langle (0.7,0.85,1.0),(0.0,0.0,0.10)\rangle $ | $\langle (0.5,0.63,0.75),(0.2,0.33,0.45)\rangle $ | $\langle (0.5,0.63,0.75),(0.2,0.33,0.45)\rangle $ | |
${C_{5}}$ | $\langle (0.2,0.33,0.45),(0.2,0.33,0.45)\rangle $ | $\langle (0.5,0.63,0.75),(0.2,0.33,0.45)\rangle $ | $\langle (0.5,0.63,0.75),(0.2,0.33,0.45)\rangle $ | |
A3 | ${C_{1}}$ | $\langle (0.0,0.15,0.30),(0.7,0.85,1.0)\rangle $ | $\langle (0.2,0.33,0.45),(0.35,0.5,0.65)\rangle $ | $\langle (0.0,0.15,0.3),(0.5,0.63,0.75)\rangle $ |
${C_{2}}$ | $\langle (0.0,0.15,0.30),(0.35,0.5,0.65)\rangle $ | $\langle (0.0,0.15,0.3),(0.5,0.63,0.75)\rangle $ | $\langle (0.0,0.15,0.3),(0.7,0.85,1.0)\rangle $ | |
${C_{3}}$ | $\langle (0.7,0.85,1.0),(0.0,0.0,0.1)\rangle $ | $\langle (0.5,0.63,0.75),(0.0,0.0,0.10)\rangle $ | $\langle (0.5,0.63,0.75),(0.0,0.15,0.3)\rangle $ | |
${C_{4}}$ | $\langle (0.0,0.15,0.3),(0.0,0.0,0.1)\rangle $ | $\langle (0.0,0.15,0.3),(0.2,0.33,0.45)\rangle $ | $\langle (0.0,0.0,0.10),(0.7,0.85,1.0)\rangle $ | |
${C_{5}}$ | $\langle (0.0,0.15,0.3),(0.0,0.0,0.1)\rangle $ | $\langle (0.0,0.15,0.3),(0.2,0.33,0.45)\rangle $ | $\langle (0.0,0.0,0.10),(0.5,0.63,0.75)\rangle $ |
Table 11
Alternatives | Criteria | Interval-valued performance ratings |
A1 | ${C_{1}}$ | $\langle (0.90,1.00,1.00),(0.00,0.00,0.10)\rangle $ |
${C_{2}}$ | $\langle (0.86,1.00,1.00),(0.00,0.00,0.10)\rangle $ | |
${C_{3}}$ | $\langle (0.59,0.74,1.00),(0.00,0.19,0.34)\rangle $ | |
${C_{4}}$ | $\langle (0.59,0.74,1.00),(0.00,0.00,0.14)\rangle $ | |
${C_{5}}$ | $\langle (0.36,0.50,0.64),(0.24,0.37,0.50)\rangle $ | |
A2 | ${C_{1}}$ | $\langle (0.86,1.00,1.00),(0.00,0.00,0.10)\rangle $ |
${C_{2}}$ | $\langle (0.74,0.81,1.00),(0.00,0.00,0.10)\rangle $ | |
${C_{3}}$ | $\langle (0.59,0.74,1.00),(0.00,0.00,0.25)\rangle $ | |
${C_{4}}$ | $\langle (0.59,0.74,1.00),(0.00,0.00,0.25)\rangle $ | |
${C_{5}}$ | $\langle (0.40,0.53,0.66),(0.20,0.33,0.45)\rangle $ | |
A3 | ${C_{1}}$ | $\langle (0.06,0.21,0.35),(0.51,0.66,0.81)\rangle $ |
${C_{2}}$ | $\langle (0.00,0.15,0.30),(0.48,0.63,0.77)\rangle $ | |
${C_{3}}$ | $\langle (0.59,0.74,1.00),(0.00,0.00,0.14)\rangle $ | |
${C_{4}}$ | $\langle (0.00,0.11,0.25),(0.00,0.00,0.31)\rangle $ | |
${C_{5}}$ | $\langle (0.00,0.11,0.25),(0.00,0.00,0.29)\rangle $ |
Table 12
Alternatives | Interval-valued performance ratings |
${A_{1}}$ | $\langle (0.75,1.00,1.00),(0.00,0.00,0.18)\rangle $ |
${A_{2}}$ | $\langle (0.69,1.00,1.00),(0.00,0.00,0.18)\rangle $ |
${A_{3}}$ | $\langle (0.18,0.34,1.00),(0.00,0.00,0.39)\rangle $ |
Table 13
Procedure I | ||
Alternatives | ${S_{i}}$ | Rank |
${A_{1}}$ | 0.856 | 1 |
${A_{2}}$ | 0.835 | 2 |
${A_{3}}$ | 0.376 | 3 |
Table 14
${A^{\ast }}$ alternatives | $\langle (0.75,1.00,1.00),(0.00,0.00,0.18)\rangle $ | ${d_{i}^{-}}$ | ${d_{i}^{+}}$ | ${d_{i}}$ | Rank |
${A_{1}}$ | $\langle (0.75,1.00,1.00),(0.00,0.00,0.18)\rangle $ | 0.00 | 1.56 | 0.766 | 1 |
${A_{2}}$ | $\langle (0.69,1.00,1.00),(0.00,0.00,0.18)\rangle $ | 0.01 | 1.56 | 0.764 | 2 |
${A_{3}}$ | $\langle (0.18,0.34,1.00),(0.00,0.00,0.39)\rangle $ | 0.24 | 0.46 | 0.228 | 3 |
Table 15
${A^{\ast }}$ alternatives | $\langle (0.75,1.00,1.00),(0.00,0.00,0.18)\rangle $ | ${d_{i}}$ | Rank |
${A_{1}}$ | $\langle (0.75,1.00,1.00),(0.00,0.00,0.18)\rangle $ | 0.00 | 1 |
${A_{2}}$ | $\langle (0.69,1.00,1.00),(0.00,0.00,0.18)\rangle $ | 0.01 | 2 |
${A_{3}}$ | $\langle (0.18,0.34,1.00),(0.00,0.00,0.39)\rangle $ | 0.24 | 3 |
Table 16
Alternatives | Procedure I | Procedure II | Procedure III | |||
${S_{i}}$ | Rank | ${S_{i}}$ | Rank | ${S_{i}}$ | Rank | |
${A_{1}}$ | 0.856 | 1 | 0.766 | 1 | 0.00 | 1 |
${A_{2}}$ | 0.835 | 2 | 0.764 | 2 | 0.01 | 2 |
${A_{3}}$ | 0.376 | 3 | 0.228 | 3 | 0.24 | 3 |
